8.4 When a Paper Misfeed Occurs
8-20 im2520f
Touch Panel Messages Chapter 8
To clear a paper misfeed in the 1st or 2nd paper drawer
1 Open the multiple bypass tray.
2 Pull up the lower-right door
release lever to open the lower-
right door of the paper feed unit
indicated in the touch panel
message.
3 Carefully pull out any misfed
paper.
4 Close the lower-right door.
5 Close the multiple bypass tray.
