6.2 Feeding the Document Through the Duplexing Document Feeder
6
im2520f 6-7
Original Documents Chapter 6
2 Slide the adjustable document
guides to fit the size of the largest
page.
3 Load the document so that all
pages are aligned along the
document guide toward the rear of
the machine.
4 Adjust the document guides to the
size of the document.
❍ Be sure to load the document
correctly, otherwise the pages
may not be fed in straight.
✎
Note
Certain document size combinations are not possible with the “Mixed Orig
Detection” function. For details, refer to page 6-3.
5 In the Basics screen, touch [Mixed
Orig Detection].
6 Select the desired copy settings,
and then press the [Start] key.
