7.1 Specifying Finishing Settings
7
im2520f 7-13
Specifying Copy Settings Chapter 7
<When the “2-Point Staple” setting is selected>
When the finisher is installed
Screen
Icon
Document Orientation Staple Position
Feeding From the Duplexing
Document Feeder
Scanning From the Original
Glass
Document size: Letter C or 5-1/
2
× 8-1/2C
Document size: Letter C or 5-1/
2 × 8-1/2C
Paper size: Letter C or
5-1/2 × 8-1/2C
Document size: Letter C or
Legal C
Document size: Letter C or
Legal C
Paper size: Letter L or
Legal L
Document size: Letter L or 5-1/
2
× 8-1/2C
Document size: Letter L or 5-1/
2 × 8-1/2C
Paper size: Letter C or
5-1/2 × 8-1/2C
Document size: Letter L or
Legal L
Document size: Letter L or
Legal L
Paper size: Letter L or
Legal L
Document size: 11
× 17 L Document size: 11 × 17 L Paper size: 11 × 17 L
